J1 Мini – Mono DI Box (J-FET, Class A)

• For critical recording, high-impedance sources.

The J1mini elevates transparency to a higher standard. Discrete J-FET transistors operating in Class A deliver exceptional clarity and the finest low-level detail retrieval in our product line.

• Sound Quality Characteristics
• Spectral Uniformity: Ultra-low THD of 0.0009% @ 0 dBu ensures zero added harmonic coloration. Tonal balance remains perfectly preserved across the frequency spectrum.
• Transient Response: Extended bandwidth to 200 kHz captures the highest-frequency transient information, resulting in precise attack reproduction and natural percussion shimmer.
• Dynamics and Distortion: J-FET input stage delivers distortion levels 3–6 times lower than D-series, with maximum headroom of +34 dBu (PAD on). Play with complete dynamic freedom without worry.
• Pianissimo Clarity: Noise floor of −110 dBu (10 dB better than D-series) ensures that low-level ambient detail, reverb tails, and subtle playing techniques emerge with pristine clarity. Perfect for mastering-grade recording.
• Ambience Reproduction: Superior noise performance and ultra-low distortion combine to preserve reverberation and spatial information with studio-reference quality.
• High-Impedance Source Compatibility: Input impedance >4.7 MΩ provides optimal loading for passive pickups, vintage keyboards, and modular synth outputs without tone sucking.

Technical Specifications

• Channels: 1
• Circuit: Discrete J-FET transistors, Class A, no overall negative feedback
• Input Resistance: ≥4.7 MΩ
• Input Impedance (PAD on): 47 kΩ
• PAD Attenuation: 20 dB
• Bandwidth: 20 Hz – 200 kHz
• Noise Level (unweighted, 10–20 kHz): <−110 dBu
• THD @ −20 dBu (guitar level): <0.001%
• THD @ 0 dBu, 1 kHz: <0.0009% (typical 0.001%)
• THD @ 0 dBu, 100 Hz: <0.0009% (typical 0.001%)
• Max Input Level (<3% THD, PAD off): >+14 dBu
• Max Input Level (<3% THD, PAD on): >+34 dBu
• Output Impedance (XLR): <33 Ω
• Power: 48V phantom power
• Dimensions: 59 × 117 × 47 mm
• Weight: 0.19 kg
